Kennedy 220 Intermediate Wave Receiver
Introduced in 1921, this was made in San Francisco, prior to Kennedy moving to St. Louis in June 1922. It is a high quality radio, mostly hand made. The tuning range is from 150 meters up to 3000 meters. The regenerative circuit uses one UV-200 detector tube.
PDF Schematic, courtesy of Nostalgia Air.
Click photo to see chassis! |
|
|
Kodel C11
One-tube radio.
Click photo to see chassis! |
|
|
Kodel C12
Two-tube radio.
Click photo to see chassis! |
|
|
Kodel C13
Three-tube radio.
Click photo to see chassis! |
|
|
Kodel C14
Four-tube radio.
Click photo to see chassis! |
|
|
Kodel Log-o-Dyne Standard Five
Five-tube radio.
Click photo to see chassis! |
